Our focus is on maintaining a high level of professionalism, service, and quality. Ceramic Band Heater is a high-efficiency and durable heating element, which is widely used in plastic machinery, chemical industry, extruder barrel heating device and various pipeline heating fields.
Ceramic Band Heater uses stainless steel as the outer shell, and uses high-insulation refractory ceramic material inside. It is heated by spiral nickel-chromium resistance wire, which has the advantages of convenient installation, high temperature resistance, fast heat transfer, and good insulation.
Ceramic Band Heater is mainly composed of the following parts:
- Shell: Made of high-quality stainless steel material, it has good corrosion resistance and mechanical strength.
- Inner layer: High-insulation refractory ceramic material, which can withstand high temperatures and maintain structural stability.
- Heating element: Spiral nickel-chromium resistance wire is inserted into the ceramic strip through a special process to form an efficient heating body.
- Insulation layer: Some products use high-temperature insulation cotton (such as aluminum silicate fiberboard) in the middle to prevent heat leakage and improve thermal efficiency.
1. Fast heat transfer and uniform heating: Ceramic band threading is adopted, which heats quickly and evenly and can reach the set temperature in a short time.
2. High temperature resistance: The maximum operating temperature can reach 600-800℃, which is suitable for heating needs in high temperature environment.
3. Good insulation: Ceramic and stainless steel materials have good insulation properties to ensure safe use.
4. Energy saving and high efficiency: The thermal efficiency can reach more than 90%, which is 1.5 times that of PTC heaters, which can effectively save energy and electricity expenses.
5. Long life: The raw materials age slowly at high temperatures, and the product has a long service life.
6. Easy installation and maintenance: The structural design is reasonable, the installation and maintenance process is simple, and even if the internal heating material is damaged, the external ceramic device can still be reused.
7. Wide range of applications: Not only suitable for plastic injection molding machines, extruders and other mechanical equipment, but also widely used in chemical, chemical fiber, electronics, medical, packaging and printing and other industries.
1.Use conditions:
Ambient temperature:-20℃~+60℃
Relative humidity:<80%
2.Electrical performance:
Working voltage:12V~380V (customizable)
Power range:50W~2000W (customizable)
Electrical strength:No breakdown within 1 minute after 1500V/50Hz sinusoidal AC voltage test
Leakage current:<0.5mA
Insulation resistance:>2MΩ
Ground resistance:<0.1Ω
3.Heat resistance:
Maximum use temperature:600-800℃
Heat resistance:The surface temperature when installed on the machine can be close to 800℃
4.Other parameters:
Power deviation value:+5%~-10%
High mechanical strength,good thermal insulation performance
Easy to install and maintain,low cost
